The Specifics of the Hook-Up Wire

When you are seeking the correct type of wire for electronic devices that are enclosed, the wire needed is likely a hook-up wire.


Hook-up wire is an important tool when it comes to applications of a low voltage and current nature. When individuals are seeking the correct type of wire for electronic devices that are enclosed, the wire needed is likely a hook-up wire. There are a variety of different types of hook-up wires on the market and the specific one needed depends on the use it will be put to. These wires differ in several areas included insulation materials and conductors as well as varying in the type of voltage that they utilize. With this in mind, it is necessary to consider the nature of the application that the hook-up wire will be utilized in when deciding on the correct choice.

The Various Uses of Hook-Up Wires

Hook-up wires can be accurately described as a variety of lead wire. Many devices use these hook-up wires as a single conductor of an insulated nature. These are the types of devices where hook-up wires are utilized.

• Appliances
• Office equipment
• Control panel equipment
• Ovens
• Automobiles
• Meter equipment

Whenever purchasing a hook-up wire, it is essential to pay attention to the voltage and wire size that is needed for the job to be tackled. With this in mind, there are many specifications related to conductors that must be adhered to.

Conductor Related Hook-Up Wire Specifications

Size -Regarding the size of a hook-up wire, the thicker the wire, the more current that it can carry. Thicker wires also present less resistance than thinner ones. The measurement known as American Wire Gauge, or AWG, is the common unit of measurement for hook-up wires in the United States of America. The higher the gauge number is for the wire in question, the smaller the diameter of the hook-up wire will be.

Material -Copper is the most commonly used conductor material in today's hook-up wires. The reason for this is the fact that copper has a strong ability to resist getting corroded. Copper is also a good material for hook-up wires due to its thermal conductivity that can withstand high heat.

Wire Type -The two primary types of hook-up wires are solid and stranded. Stranded wires have a more malleable nature than solid wires. This is because stranded conductors are composed of wires that have been twisted up together.

Material Type -Materials such as silicon rubber, neoprene, and PVC material are the common mediums for the jackets that protect hook-up wires. These materials keep the wire protected. They also help in the prevention of the current leaking out of the conductor.

Voltage -Regarding hook-up wire voltage, applications that require less than 1 kV are considered to be low voltage while anything from one to 36 kV and anything above this is ranked under the classification of medium voltage and high voltage. It is in applications of low voltage that hook-up wires are best suited.
